The cost of direct handling can be reduced by more than 25% compared with manual handling.
The unit of goods to be transported can be enlarged and the time to be transported can be saved.
Reduce the damage of moving articles and improve the success rate of products.
Reduce labor intensity and improve working conditions.
Good maneuverability, diversified working performance, reduce other handling equipment, reduce the investment of the entire handling facilities.
Model | MPT15 MPT20 | ||
Features | Drive system | Battery | |
Driving mode | Standing | ||
Load Capacity | Q(kg) | 1500/2000 | |
Load Center | C(mm) | 600 | |
Weight | Weight(With battery) | kg | 150 |
Wheels | Material | PU | |
Size | Lifting Height | H3(mm) | 195 |
Min/max.height of handle when operating | H4(mm) | 690/1100 | |
Min.Height of Fork | S(mm) | 85 | |
Length | L(mm) | 1605 | |
Width | B(mm) | 560/685 | |
Fork Length | L2(mm) | 11150 | |
Wheelbase | Y(mm) | 1202/1261 | |
Fork Outside Width | B1(mm) | 550/685 | |
Min.Turning Radius | Wa(mm) | 1460 | |
Performance data | Driving Speed (Empty/Full Load) | Mm/s | 4/4.5 |
Lifting Speed (Empty/Full Load) | Mm/s | 0.027/0/038 | |
Descending Speed (Empty/Full Load) | Mm/s | 0.059/0.039 | |
Max.Gradient (Empty/Full Load) | % | 5/16 | |
Brake | Electromagnetic brake | ||
Driving Motor | KW | DC/0.65 | |
Lifting Motor | KW | DC/0.84 | |
Battery | Capacity | V/Ah | 48//15 |
